Design & engineering
Free Dialux Lighting Design & Full Project Support
Mast Lighting provides a free professional Dialux simulation for outdoor lighting projects, then supports the project through specification, production, installation, commissioning and after-sales. Engineering is part of the supply, not an invoiced extra.
What the free Dialux design gives you
A lighting design answers a question a datasheet cannot: will this particular layout, on this particular road, reach the illuminance and uniformity the project is contracted to achieve. We model the proposed installation in Dialux and report the result before anything is manufactured — which is also how a specification gets corrected while correcting it is still free.
- Illuminance and luminance calculation for the proposed layout
- Uniformity ratio across the carriageway or working area
- Glare assessment for the selected optics and mounting height
- Pole height, spacing and arm/tilt recommendation
- Luminaire selection and wattage confirmation
- A simulation you can attach to a tender submission
What we need from you
| Road or area geometry | Width, number of lanes, length, median or footway arrangement |
|---|---|
| Mounting arrangement | Single side, staggered, opposite or central, plus proposed pole height |
| Spacing | The spacing you are considering, or the pole positions already fixed |
| Target standard | The lighting class or illuminance level the project must achieve |
| Power source | Mains supply, off-grid solar, or hybrid switching |
| Site conditions | Climate, wind zone and any obstruction or shading |
Service scope
Support across the whole project life
Mast Lighting integrates research and development, production, engineering contracting and export in one organisation, which is why the same company that designs the light source can also commission the installation.
Free Dialux lighting design
Mast Lighting provides a professional Dialux simulation at no charge for project enquiries. The design is produced from your road dimensions, pole height, installation spacing and the local illumination standard, and if the first configuration misses the target we adjust wattage, optics, height or spacing until it complies.
Product selection and configuration
Our engineers translate the photometric result into a buildable specification: LED wattage, optical distribution, LiFePO4 capacity and autonomy days, photovoltaic panel power, pole height, wall thickness and finish, and the smart control strategy.
Engineering contracting
Beyond supply, Mast Lighting undertakes municipal infrastructure, intelligent building, landscape, sports facility and earthwork engineering, along with equipment maintenance, installation and engineering management — so a project can be handled as one scope rather than split across trades.
Installation and commissioning support
Products ship with installation documentation, and we provide commissioning guidance for controllers, dimming profiles and hybrid solar/grid switching. Customized installation approaches are prepared for difficult environmental conditions.
Remote troubleshooting and maintenance
After handover we support the maintaining contractor with remote troubleshooting and maintenance guidance — panel cleaning intervals, battery health checks over the 5–8 year LiFePO4 service life and ingress-seal inspection.
Warranty and after-sales
Solar street lights carry a 3-year warranty. Because the luminaire, pole, panel and battery come from one factory, a warranty question does not turn into a dispute between suppliers.
How it works
Four steps from enquiry to supported installation
- 01
Share the project
Send road dimensions, mounting height, spacing and the lighting class the project must meet.
- 02
Receive the design
Our engineers return a Dialux simulation with illuminance, uniformity and glare results, plus a recommended configuration.
- 03
Confirm specification and price
Wattage, storage, panel, pole and controls are fixed against the design, and factory-direct pricing is issued.
- 04
Production, shipping and support
Staged inspection, direct export under our own import/export rights, then installation, commissioning and after-sales support.
Products covered
Design support across the full range
The design service covers everything we manufacture: solar street lights from 50W to 300W with 3–7 rainy-day autonomy, LED street lights from 120W to 320W reaching 200–220 lm/W, high mast systems from 20m to 60m and hot-dip galvanized poles engineered for Grade 12 typhoon wind.
Scenario-specific guidance is set out in the lighting solutions pages, and OEM/ODM customization lets the resulting specification be produced under your own brand.
See the product rangeService questions
About the design service
Is the Dialux lighting design really free?
What information do you need to produce a street lighting design?
What standards do you design to?
What lux level is recommended for street lighting?
Do you support installation and commissioning?
Send the road dimensions and we will design the lighting
Width, length, mounting height, intended spacing and the lighting class you must meet. There is no design fee and no obligation to order.
